SPI/IIC GY-9250 BMP280 GY-91 MPU6500 6-Axis 9-Axis 10DOF Attitude Gyro+Accelerator+Magnetometer Sensor Module(GY-6500 with pin)

SensorsMain FeaturesGY-65001. This module contains 16-bit ADC output of 3 axis accelerator and 3 axis gyro2. Model : GY-65003. Chip : MPU65004. Power voltage : 3 - 5V5. Communication mode : I2C/SPI Communication Protocol6. Gyro range : +/-250, +/-500, +/-1000, +/-2000 dps7. Accelerator range : +/-2G, +/-4G, +/-8G, +/-16G8. Register : 1MHz9. SPI / I2C : 400KHz10. Gyro working current : 3.2mA11. Gyro sleeping current : 8uA12. Accelerator working current : 450uA13. Accelerator sleeping current : 8uA14. Size : 15mm*25mmGY-9250MPU-9250 modules (three-axis gyroscope + triaxial accelerometer + triaxial magnetic field)Use Chip: MPU-9250Power supply :3-5v (internal low dropout regulator)Communication: IIC / SPI communication protocol-Chip 16bit AD converter, the output data 16Gyro range: ± 250 500 1000 2000 ° / sAcceleration range: ± 2 ± 4 ± 8 ± 16gMagnetic field range: ± 4800uT2.54mm pin pitchModule size 15mm * 25mmGY-9255Power supply: 3-5v (internal low dropout regulator) Communication: IIC communication protocol Built-in 16bit AD converter, 16-bit data output Gyroscopes range: ± 250 500 1000 2000 ° / s Acceleration range: ± 2 ± 4 ± 8 ± 16g Magnetic field range: ± 4800uT Using of Immersion Gold PCB, machine welding process to ensure quality 2.54mm pitch Module size 15mm * 25mmHign-concerned Chemical : NonePackage : SMDApplication : AlarmType : Module
